Solar Star Light Pro
Max 160W 16000LM LiFePO4 Battery 1536WH
MPPT smart control system 100% Brightness the whole night available
E-mail: info@socreat.com
Mobile: +86 136 9226 2895
MPPT is an advanced charge mode whose full name is Maximum Power Point Tracking function which can increase the energy utilization rate by 15% to 20% than the PWM controller
Road Smart new patent solar controller adopts multi-peak MPPT technology, which can timely track the maximum power point and improve the conversion efficiency of solar panels.
Through 10years’ experience, Road Smart upgraded highly precise 5.0 version IPC technology (intelligent power control 5.0). It will intelligently detect recent weather conditions, reasonably plan the discharge power to achieve more rainy days.
Using Grade A LiFePO4 battery with excellent safety performance. Road Smart's unique current equalization and dual protection (software and hardware) enable the battery’s capacity remains at 90% after 2000 cycles. Lifetime is 4 times longer than that of lead-acid batteries.
The single-string 3.2V MPPT technology reduces the probability of battery problems by 75% than that of multi-string 12V technology, effectively improved the overall product stability and extended lifetime over 3 times.
Road Smart integrate two cores CPU into one processor to improve the operational speed of solar controller and reduce half probability of damage by data backup function, improve output power double than others.
Road Smart self-developed patent solar controller adopts LPCV technology (High-precision Constant Voltage Management) brings lower ripple, improves circuit efficiency, and extend lifetime of circuit and battery.
4pins plug technology to enables transportation power consumption less than 0.05mA, and circuit protection technology to enables the sleep power consumption in long-term transportation of storage will be at uA level, realizing worry-free storage for two years.
Automatically Switch off function by software at temperature limit to protect battery from long time high temperature working. Heating up function to protect battery at Low temperature atmosphere. Extend longer lifetime of the whole system.
Road Smart system have mode memory storage function to realize one-time operation and permanent preservation.
|
|
Type |
SP-110
|
SP-160
|
SP-165
|
| LIGHT |
Power
|
65W
|
80W
|
100W
|
|
LED chip
|
SMD3030/200pcs
|
|||
|
LED Brand
|
Bridgelux
|
|||
|
IP Rating
|
IP65 | |||
|
Flux @ CCT 5700-6000K
|
10400LM
|
12800LM
|
16000LM
|
|
|
CRI
|
70 / 80
|
|||
|
Beam angle
|
140*60
|
|||
|
Light distribution
|
Bat-wing Type II
|
|||
|
Shell material
|
Aluminum alloy
|
|||
|
Working temperature
|
-20°C to 60°C
|
|||
|
Lifespan
|
50000hrs
|
|||
|
BATTERY
|
Power
|
768WH
|
1152WH
|
1536WH
|
|
Lighting time @ Full power
|
11.82hrs
|
14.4hrs
|
15.36hrs
|
|
|
Lighting time @ Dimming/Power
control
|
3-5days
|
|||
|
Lithium battery
|
LiFePO4
|
|||
|
Charging cycles
|
>2000times
|
|||
|
SOLAR
PANEL
|
Power
|
110W
|
160W
|
160W
|
|
Voltage
|
18V
|
|||
|
Type
|
Monocrystalline silicon
|
|||
|
Efficiency
|
22%
|
|||
|
Lifespan
|
>25years
|
|||
|
CONTROLLER
|
Charging method
|
Multi-peak MPPT
|
||
|
Working modes
|
L / M / T / U
(Compound with photocell sensor, timing, dimming, microwave
sensor, intelligent power control saving)
|
|||
|
Circuit protection
|
High / Low temperature protections
|
|||
|
Short circuit & Open load protections
|
||||
|
Overcharging & Overdischarging protections
|
||||
|
INSTALLATION
|
Top diameter
|
76mm
|
||
|
Height
|
7-8m
|
9-10m
|
11-12m
|
|
|
Spacing
|
30m
|
35m
|
40m
|
|
|
WARRANTY
|
3yeras on all components - option to extend
|
|||
LED Chip
MPT multi-string protection
board test system
Waterproof Test
High/low Temperature Test
Anti-shocking Test
Multi-channel temperature
recorder
