Energy Storage RS-EOS

Long life and safety

Vertical industry integration ensures more than 6000 cycles with 80% DoD.
Easy to install and use

Small size, minimizing installation time and cost compact and stylish design suitable for your sweet home environment.
Intelligent

Each battery with independent BMS system manages power output smartly and effectively.
Scalability

You can use 4 batteries in parallel at the same time,and can provide a maximum of 20 kWh for your use.
Compatibility

Compatible with most of the available hybrid inverters.

Technical Parameter Classic Working Mode Application

Product model	RS-S4850A-E0	RS-S48100A-EO
Dimentions(LWH)	620450140mm	1014620191mm（320.6ft）
Weight	46kg	88kg
Rated Energy	5.12kWh	10.24kWh
Rated Capacity	100Ah	200Ah
Life time(25°C)	20 Years
Life cycles (80% DOD,25°C)	6000 Cycles
Rated voltage	51.2V
Max.charging voltage	57.6V
Over discharge voltage	44.8V
Battery type	LFP
Communication interfaces	CAN/RS232/RS485
Constant charging current	100A	150A
Constant discharging current	100A	200A
Peak charging current	110A (3S)	220A (3S)
Peak discharging current	110A (3S)	220A (3S)
Max.Number of parallel	4	9
Lithium Battery Standard	UN38.3,MSDS,EN55032,EN55024, EN61000-3-2,EN61000-3-3
Storage time / temperature	6 months @25°C；3 months @35°C；1 months @45°C
IP	IP54	IP65
Operation Environment	Indoor	Outdoor/Indoor
Charging temperature range	0~45°C
Discharging temperature range	-10~45°C
Cooling method	Natural cooling
